3D Leveraging AM for Auto Production
the need for further post-processing. Full stacking, often deemed difficult with LPBF due to thermal stresses involved in the layer process, was achieved through intelligent design of the structure. This reduced thermal stresses, leading to min- imal thermal distortion. Innovative part design enabled a series of parts to be nested to maximize build volume, resulting in 384 parts produced within a single build envelope. UK-based Progressive Technol- ogy (www.progressive-technology.co.uk) built the parts using an EOS 280M system.
Reduced Build Times and Costs
Betatype’s design and data-processing technology enabled every toolpath within each part to be designed, managed and optimized. Through specific control parameters, exposure of the part in each layer to a single laser-melting toolpath was reduced significantly, with minimal delays in between. This, coupled with the company’s optimization algorithms and process technology, reduced build time
A stacked build of automotive LED- headlight heatsinks. Designing the part with in-built support features allowed multiple parts to be stacked on top of each other without the need for additional supports. As a result, finished parts could be snapped apart by hand, without the need for further post- processing.
of each part from 1 hr. to less than 5 min. —reportedly 10 times faster than using a standard build processor.
Reducing build times is key to making parts more cost-effective with LPBF, as equipment amortization represents a major part-cost driver. Betatype’s opti- mization technology played a significant role here in decreasing cost/part from $40-plus to less than $4.
Moreover, on single-laser, medium-frame printing systems, this technology helped reduce build time from 444 hr. to less than 30 hr. for the 384 parts. With new multi- laser, medium-frame systems this optimiza- tion approach reduced build time to less than 19 hr. Using these high-productivity systems, it was possible to realize a 19-fold gain in productivity across a year of pro- duction per system, from 7055 to 135,168 parts. Installation of seven machines running the optimized process results in volumes approaching 1 million parts/yr. 3DMP
Article supplied by Betatype, London, United Kingdom; www.betaty.pe.
