Page 37 - 3D Metal Printing Winter 2018

Hilkene suggests. “For one, ‘more user friendly’ is not the same thing as ‘user friendly.’ This technology requires a two- step process, including post-print sinter- ing after the initial extrusion. Part-shrink- age rates during sintering can fall in the 20 to 30-percent range, which requires some smart software from the OEMs and a learning curve for operators to accurately predict and account for these changes in dimension to hit critical tolerances.”
Hilkene also warns that surface finish may be another area to ask questions, as post-processing is required of all metal 3D-printing systems, and that may be espe- cially the case for extrusion metal printing.
“Polymer extrusion systems often are knocked for having the most easily visible layer lines of any 3D-printing process. How- ever, finishing of green (unsintered) parts and sintered parts should help this—anoth- er element for customers to consider.
“We don’t see these printers as pow- der-bed killers,” Hilkene continues. “Rather, they represent just one more tool, bringing unique benefits for certain indus- try applications.”
On the whole, Hilkene views extrusion metal systems as a significant positive for the industry. “While we anticipate the aero- space and medical industries will continue to lean heavily on powder bed for their 3D printed-metal parts,” he says, “extrusion machines also will find uses in those indus-
tries. Beyond that, we foresee extrusion metal systems making metal 3D printing more accessible to other industries that may be attracted to some of the material options and relatively low cost, such as industrial products, energy and automotive.”
More Production Stories
Hilkene puts the arrival of metal extru- sion printing within the broader context of the industry. “Word is getting out about some of the practical applications for addi- tive,” he says, “and that’s leading to more companies testing the waters. We’re seeing new applications all the time, and not just for prototyping. The industry is pushing for acceptance of the processes for tooling and for the ‘holy grail’ of production.”
Hilkene expects the continued expan- sion of AM as a production technology. “More announcements will come out regarding metal-AM parts being approved for production use by the Food and Drug Administration and Federal Aviation Administration,” he says. “In turn, news of the success of these parts in the market will start leaking out. There’s no question that metal-AM processes can improve part performance, we just have to find the low- est hanging fruit while AM gradually becomes more affordable. We’ve seen recent examples—Norsk Titanium, for example, early in 2017 received FAA approval to print structural parts for jets.
This and other announcements create a comfort level for companies to keep push- ing for new applications.”
Speed—Last but Not Least
Hilkene’s final thoughts center on the coming buzz about increased processing speed. “On the polymer side,” he says, “we have heard a lot of headlines about new products launched by HP, Carbon and others. I can say from our experience that there’s a lot of fire to go along with the smoke. We’re seeing 3D printers capa- ble of handling larger quantities cost- effectively due to improvements in speed and overall economics.
“On the metals side,” he continues, “we will see some speed increases with pow- der-bed systems, but speed probably doesn’t take a big step forward until at least late-2018 or 2019. That’s when we expect to see next-generation binder-jetting tech- nology come into the market, pushing the boundaries of how fast metal printing can occur (at least for certain geometries). In the meantime, speed and productivity increases will for the most part be incre- mental. Machines with extra energy sources (e.g., lasers) can provide more speed to powder-bed systems, and emerging tech- nologies such as DED can dispense more powder, but metal-additive annual pro- duction quantities exceeding 1000 parts will be for a very select subset of parts.” 3DMP
